The sodium-ion (Na-ion) batteries represent an emerging technology that promises to revolutionize the electric mobility market, including the growing electric bicycle industry. This technology uses sodium, an abundant and easily accessible element, as the basis for its operation, offering a sustainable and economical alternative to traditional lithium batteries.
In this guide, we will explore in detail how sodium-ion batteries work, their advantages, limitations, applications in electric bikes and best practices for their use.
1. What are Sodium-Ion (Na-ion) batteries?
Sodium-ion batteries share similar operating principles with lithium-ion batteries, but use sodium ions for charge transfer. This substantial difference allows for reduced production costs and mitigates supply issues related to lithium.
Chemical composition
Na-ion batteries are composed of:
- Anode: made from carbon-based materials, such as hard carbon.
- Cathode: made up of sodium compounds, such as sodium oxide.
- Electrolyte: a conductive solution that allows the movement of ions between anode and cathode.
- Separator: a membrane that prevents direct contact between anode and cathode.
2. How do Sodium-Ion batteries work?
The operating principle is based on the transfer of sodium ions through the electrolyte:
- During charging, sodium ions move from the cathode to the anode, storing chemical energy.
- During discharge, the process is reversed: the ions return to the cathode, releasing electrical energy that powers the electric bike's motor.
Despite slightly lower efficiency compared to lithium batteries, Na-ion batteries offer advantages in terms of sustainability, cost, and lifespan, making them promising for use in e-bikes.
3. Advantages of Sodium-Ion batteries
What are the advantages of using these batteries? Let's find out.
1. Abundance of materials
Sodium is the sixth most abundant element on Earth, easily accessible and less expensive than lithium. This abundance eliminates issues related to the supply of rare materials.
2. Reduced costs
Na-ion batteries are generally cheaper to produce thanks to the use of less valuable materials.
3. Safety
They have greater thermal stability compared to lithium batteries, reducing the risk of overheating or fire. They also work well at extreme temperatures, making them suitable for different climate conditions.
4. Eco-friendliness
Production with reduced environmental impact. Easier to recycle compared to lithium batteries, as they do not contain cobalt or nickel in large quantities.
5. Consistent performance
They provide stable performance even in scenarios of intense use and at low temperatures.
The battery has an ultra-long range, capable of reaching 50 kilometers even at temperatures below 0°C while maintaining a speed of 25km/h.
- The life cycle exceeds 4,000 cycles
- The battery maintains about 93% of its capacity even in extreme cold conditions of -20°C, making it exceptionally suitable for winter use.
- charging speed in less than 20 minutes to 100%
- In addition, the battery's safety performance exceeds industry standards thanks to IPX7 waterproof technology that covers the entire pack
Specification:
Charge 2C at 90% DoD / Discharge 2C
Charge 90% DOD at constant current 2C, 25°C ± 5°C, discharge to 2.5 V at 2C taking as an example the battery from
After 10 years of daily use, we would have a voltage drop to 45V, allowing us to use the battery at 40V for half the range even after 68 years if used once a day.
The retention capacity is 96% after 3850 cycles, the expected lifespan at 80% SOH is >25,000 cycles.
Test of a slight uphill route on a bike path and ambient temperature of 29 degrees
4. Limits of Sodium-Ion Batteries
What are instead the limits of this type of battery?
1. Lower energy density
Na-ion batteries offer an energy density of about 90-160 Wh/kg, lower than the 200-250 Wh/kg of lithium batteries. This means they are heavier for the same capacity.
2. Life cycles
Although the life cycles are very good (2,000-4,000 cycles), like LiFePO₄ (lithium-iron-phosphate) batteries, customers prefer capacity, but almost all modern ebikes use NMC batteries that last only 400 cycles. Considering the fast degradation and low use of the cells, the values are in favor of sodium: with the same initial cost, they last 10 times longer.
3. Size
Due to the lower energy density, Na-ion batteries can be bulkier.
5. Applications of Sodium-Ion Batteries in Electric Bikes
Na-ion batteries are particularly suitable for electric bikes intended for:
- Urban mobility: where the extra weight is not a critical factor and affordability is an advantage.
- Bikes for harsh climates: thanks to their ability to operate in a wide range of temperatures.
- Sustainable solutions: ideal for those looking for an eco-friendly alternative to traditional lithium batteries.
6. How to Choose a Sodium-Ion Battery for Your e-Bike
Let's move on to the tips to follow when choosing.
1. Capacity
The capacity of the battery is measured in Wh (Watt-hours) and is a direct indicator of range. A battery of:
- 350 Wh could provide 30-50 km of range.
- 500 Wh could provide 50-80 km of range.
- 750 Wh would extend the range to 100 km or more.
2. Voltage
Check that the voltage (36V or 48V) is compatible with the motor of your bike.
3. Weight
Keep in mind that sodium-ion batteries tend to be slightly heavier than lithium ones, but the extra weight is often offset by lower costs.
7. Maintenance of Sodium-Ion Batteries
Charging, storage, and cleaning... how to perform maintenance of Sodium-Ion batteries in the best way?
Charging
- Recharge the battery before it drops below 20% to preserve its lifespan.
- Use only the charger provided by the manufacturer.
Storage
- Store the battery at a medium charge (50-60%) if you don't plan to use it for long periods.
- Avoid exposing the battery to temperatures above 40°C or below -10°C.
Cleaning
Keep the contacts clean and dry to ensure an efficient connection.
8. Future of Sodium-Ion Batteries in e-Bikes
Sodium-ion batteries are still in the commercial development phase, but are already showing great potential:
- Several companies are optimizing energy density to approach the performance of lithium batteries.
- Their application will likely extend to larger vehicles, but electric bikes represent an ideal springboard thanks to their moderate energy requirements.
9. Comparison: Sodium-Ion vs Lithium-Ion
Conclusion
Sodium-ion batteries represent a promising innovation in the electric bike sector, offering an ecological, safe, and economical solution. Although they have some limitations in terms of energy density, their advantages in terms of cost and sustainability make them an interesting choice for the future of electric mobility.
Investing in an electric bike with a sodium-ion battery today means embracing a cutting-edge technology that could soon become the standard in the industry.
